Overview

The UBEC uses an efficient DC-DC regulator chip with a conversion efficiency of more than 90%. UBEC output voltage is adjustable in three stages (6.0/7.4/8.4 V) with a continuous current of 10A and a maximum of 25A. The voltage specifications allow the use for a wide range of servos and electrical equipments. The UBEC is equipped with overcurrent protection, output short-circuit protection, overheat protection.

Specifications

ModelUBEC 10A
Input voltage3-14S Lipo
Output voltage6.0 / 7.4 / 8.4 V (3 options adjustable)
Output currentContinuous 10AInstantaneous 25A
Measurement55*25*12mm
Weight 35g
