Special Order: Processing time is about3 – 10 business days

K-235G4DESCRIPTION

• KingTech G4 utilizes SBus data transmission.
  Engine/ECU integration, all operating parameters including total run time are all recorded into the engine.
  The smaller and lighter external Data Relay Module (DRM) is responsible for all data, signal and power transmission.
  Pump: digital sbus brushless pump
  A micro USB connector is present for a future connectivity of wireless mobile apps.
  The G4 features a brushless starter motor for reliability and durability, built-in FOD screen is also integrated.
  After a run cycle and receiver switched off, GSU will remain on only until cool down completes.

K-235G4 SPECIFICATIONS

Diameter: 119 mm ( 4.68″ )
Length: 278 mm ( 10.94″ )
Weight: 2.0 kg ( 4 lb 6.4 oz )
RPM Range: up to 33,000-109,000RPM
Thrust: 23.5 kg @ max RPM ( 51 lb 12.8 oz )
EGT: 750C max
Fuel consumption: 680 g / min ( 23.98 oz / min )
Fuel: Diesel, Jet A1, Kerosene
Lubrication: 5%
Maintenance cycle: 25 hr

G4 MODEL COMPONENTS LIST

Engine
Data Relay Module (DRM)
Ground Support Unit (GSU)
Wire Harness and Tubing Set
Fuel Pump, Filter and Shout-off Valve
Fuel Inlet Attchments
Instruction Manual
